KM-SPV11 Subsea Phantom Vessel

A synthesis of fast surface crafts and subsurface diver delivery crafts to get both capabilities in a single solution.

KM-SPV11 is a special operations vessel capable of approaching the mission area at surface at high speed and then penetrating high-risk area underwater in a silent and stealthy mode. The vessel has two seperate propulsion systems for surface and subsurface operations. The divers travel in a flooded cabin underwater by benefitting the vessel’s central breathing system. Critical equipment and systems are protected by watertight enclosures.

Main Characteristics

Specification

Value

Overall Length
10.58 m
Beam
2.21 m
Displacement
7 Tons
Cruise Speed
25 Surface / 5 Subsurface Knots
Max Speed
27+ Surface / 5 Subsurface Knots
Range @ Cruise Speed
150 Surface / 15 Subsurface NM

Propulsion & Power

System

Details

Main Propulsion & Maneuvering
1 x 250 kW Diesel 1 x Waterjet 2 x 10 Kw Electric Motor Thrusters Rudders&Fins
Power Generation
2x20 kWh Battery Pack

Crew Capacity

2 Drivers
6 Divers

Electronics

DGPS
Active Search Sonar
Thermal Camera System
