KM-FAC40 Fast Attack Craft-40M

Littoral Protection — Large, High-Speed Fast Attack Craft

Big brother of the Fast Attack Craft family: the KM-FAC 40 is an all-aluminium, large fast attack craft delivering 50 knots — an extraordinary speed for a vessel of its size. Purpose-built for littoral attack, territorial waters protection, and maritime patrol duties, the platform is configured to carry small to medium caliber gun systems and mission-specific fittings to support sustained littoral operations and force projection tasks.

Main Characteristics

Specification

Value

Overall Length
40.5 m
Beam
8.37 m
Displacement
220 Tons
Cruise Speed
18 Knots
Max Speed
50 Knots
Range @ 18 Knots
850 NM

Propulsion & Power

System

Details

Main Propulsion & Maneuvering
3 x 4300 kW Diesels 3 x Waterjets
Power Generation
2 x 200 kW Diesel Generator 1 x 110 kW Emergency Generator

Crew Capacity

4 Officers
9 Petty Officers
12 Ratings

Electronics

Navigation Radar
GPS
ECDIS
Magnetic and Satellite Compass
Speedlog
Echo Sounder
VHF & UHF Comm.
AIS
INMARSAT

Weapons

1x 30 mm Remote Operated Gun
2x 7.62 mm Mach. Guns (Optional)
